GENTILIN - Smart 2.25 Dry Air Compressor 230-50V-Hz
Gentilin Smart 2.25 Dry – Quiet Oil-Free Compressor with Adsorption Dryer
The Gentilin Smart 2.25 Dry is a high-performance air compressor designed for professionals who need a steady supply of clean and dry compressed air. Built in Italy with advanced technology, it combines strong performance, low noise, and reliable drying capacity, making it ideal for dental clinics, laboratories, medical environments, food processing, and workshops.
This model is equipped with a 1.5 kW (2 HP) motor and two cylinders, running at 1,400 rpm. It delivers an air intake of 220 L/min, with 140 L/min at 5 bar and 120 L/min at 8 bar, reaching a maximum pressure of 8 bar. This makes it powerful enough for demanding applications that require consistent airflow.
The key feature of the Smart 2.25 Dry is its built-in adsorption dryer, which reduces the dew point to –20 °C. This guarantees dry, moisture-free compressed air that meets the ISO 8573-1 Class 4-3-0 standard. With such air quality, you avoid contamination, corrosion, and product damage, which is especially critical in medical, dental, and food sectors.
The compressor comes with a 24-liter epoxy-coated tank, protected both inside and outside for durability and long life. Despite its power, the Smart 2.25 Dry is impressively quiet, producing only 65 dB measured at 3 meters and 5 bar — about the level of normal conversation.
Technical highlights:
-
Voltage: 230 V, 50 Hz – Absorption: 7 A
-
Tank capacity: 24 L, epoxy coated
-
Noise level: 65 dB
-
Duty cycle: S3, 70% on / 30% off
-
Dimensions: 470 × 420 × 820 mm
-
Weight: 40 kg (52 kg packaged)
-
Options: Hour meter, automatic tank drain valve
If you need a compact, quiet, and reliable compressor with dry, oil-free air, the Gentilin Smart 2.25 Dry is the perfect choice. It ensures professional performance while protecting sensitive equipment and processes with clean, moisture-free compressed air.
Manual Download
Catalog Download
Certifications Download
| Technical Data | |
|---|---|
| Condensate Treatment | Adsorption Dryer | Dew Point -20°C |
| Particulate Treatment | - |
| Air purity class (ISO 8573-1) | 4-3-0 |
| Voltage (V) | 230,00 |
| Frequency (Hz) | 50,00 |
| Nominal rating (kW) | 1,50 |
| Nominal rating (HP) | 2,00 |
| Rotation speed (rpm) | 1.400,00 |
| Absorption (A) | 7,00 |
| Number of cylinders | 2 |
| Air intake (L/min) | 220,00 |
| Air Delivery (L/min @5 bar) | 140,00 |
| Air Delivery (L/min @8 bar) | 120,00 |
| Maximum pressure (bar) | 8,00 |
| Noise level (3,00m @ 5,00 bar) (dB(A)) | 65,00 |
| Duty cycle | S3 70% |
| Tank Coating | Epoxy (interior/exterior) |
| Tank capacity (lt) | 24,00 |
| First Maintenance (hours) | - |
| Hour Meter | Optional |
| Tank Automatic Drain Valve | Optional |
| Product Dimensions | |||
|---|---|---|---|
| Length (mm) | Width (mm) | Height (mm) | Weight (Kg) |
| 470,00 | 420,00 | 820,00 | 40,00 |
| Single Piece Packaging Dimensions | |||
| Length (mm) | Width (mm) | Height (mm) | Weight (Kg) |
| 570,00 | 680,00 | 950,00 | 52,00 |
| Full Pallet Packaging | Details | ||
| Dimensions (cm) - LxWxH | 1140x680x1900 | ||
| Weight (Kg) | 228,00 | ||
| Pieces | 4 | ||
**All our products are brand new, shipped in the original packaging, and include manufacturer warranty**
