GENTILIN - Qube 550 H - Dry Air Compressor 400-50V-Hz
Gentilin Qube 550 H Dry - Ultra Quiet Oil-Free Compressor with Membrane Dryer (10L Tank)
The Gentilin Qube 550 H Dry is a compact yet powerful compressor designed to deliver very dry and oil-free air with exceptionally low noise. Built in Italy, it combines a high-output pump, advanced membrane drying technology, and continuous-duty performance, making it ideal for clinics, laboratories, workshops, and industries that require dry compressed air every day.
Strong and continuous performance
This compressor runs on a 4.0 kW (5.5 HP) motor with four cylinders, operating at 1,400 rpm. It provides an air intake of 660 L/min, with 366 L/min at 5 bar and 320 L/min at 8 bar, reaching a maximum pressure of 10 bar. With an S1 duty cycle (100% on), the Qube 550 H Dry is built for uninterrupted use, supplying a reliable flow of air for demanding applications.
Built-in membrane dryer
The standout feature of this model is its integrated membrane dryer, which reduces the dew point to -40 °C. This ensures dry compressed air, free of moisture, suitable for sensitive equipment and processes. It delivers air quality in line with ISO 8573-1 Class 3-2-0, preventing humidity-related problems and extending the life of tools and machinery.
Compact 10L tank with epoxy coating
The Qube 550 H Dry is fitted with a 10-liter epoxy-coated tank, designed to resist corrosion both inside and outside. The tank is compact yet durable, providing steady air storage while keeping the unit easy to place in restricted spaces.
Extremely low noise
Despite its high airflow, the Qube 550 H Dry operates at just 52 dB measured at 3 meters and 5 bar. This makes it one of the quietest compressors in its performance class, perfect for installation in clinics, labs, and offices where silence is important.
Standard features
The compressor comes with an hour meter for usage tracking. An automatic condensate drain valve is available as an option. Maintenance needs are minimal, with the first service required only after 10,000 hours, keeping operating costs low.
Technical highlights
-
Voltage: 400 V, 50 Hz - Absorption: 6.5 A
-
Motor: 4.0 kW (5.5 HP), 4 cylinders
-
Air intake: 660 L/min
-
Air delivery: 366 L/min at 5 bar, 320 L/min at 8 bar
-
Max pressure: 10 bar
-
Tank: 10 L, epoxy coated
-
Duty cycle: S1 100% continuous duty
-
Noise level: 52 dB
-
Dimensions: Compact with 10 L tank
-
First maintenance: 10,000 hours
The Gentilin Qube 550 H Dry is the right choice if you need a quiet, oil-free compressor with membrane drying technology in a compact design for professional use.
Catalog Download
Certifications Download
| Condensate Treatment | Membrane dryer | Dew Point -40°C |
|---|---|
| Particulate Treatment | - |
| Air purity class (ISO 8573-1) | 3-2-0 |
| Voltage (V) | 400.00 |
| Frequency (Hz) | 50.00 |
| Nominal rating (kW) | 4.00 |
| Nominal rating (HP) | 5.50 |
| Rotation speed (rpm) | 1,400.00 |
| Absorption (A) | 6.50 |
| Number of cylinders | 4 |
| Air intake (L/min) | 660.00 |
| Air Delivery (L/min @5 bar) | 366.00 |
| Air Delivery (L/min @8 bar) | 320.00 |
| Maximum pressure (bar) | 10.00 |
| Noise level (3.00m @ 5.00 bar) (dB(A)) | 52.00 |
| Duty cycle | S1 100% |
| Tank Coating | Epoxy (internal/external) |
| Tank capacity (lt) | 10.00 |
| First Maintenance (hours) | 10000 |
| Hour Meter | Included |
| Tank Automatic Drain Valve | Optional |
**All our products are brand new, shipped in the original packaging, and include manufacturer warranty**
