GENTILIN - Qube 300 - Air Compressor 230-50V-Hz
Gentilin Qube 300 - Ultra-Quiet Oil-Free Compressor with 40L Tank
The Gentilin Qube 300 is a compact, powerful, and ultra-quiet compressor designed for long and steady use. Built in Italy, it delivers strong airflow, a robust tank, and very low noise levels, making it ideal for clinics, laboratories, offices, and workshops where silence and reliability are essential.
Strong and continuous performance
This model is powered by a 2.2 kW (3 HP) motor with two cylinders, operating at 1,400 rpm. It provides an air intake of 330 L/min, with 210 L/min at 5 bar and 185 L/min at 8 bar, reaching a maximum pressure of 10 bar. With an S1 duty cycle (100% on), the Qube 300 can run continuously without pauses, making it suitable for applications that require a steady supply of compressed air all day.
Extremely low noise
One of the most impressive features of the Qube 300 is its sound level. Operating at only 47 dB measured at 3 meters and 5 bar, it is one of the quietest compressors in its class. This makes it perfect for sensitive environments where silence is important, such as dental practices, medical rooms, and laboratories.
Durable 40L tank with epoxy coating
The compressor includes a 40-liter tank, coated with epoxy both inside and outside to resist corrosion and extend service life. This ensures long-term durability even under continuous workloads.
Included features
The Qube 300 comes fully equipped with an hour meter to monitor usage and plan maintenance easily. It also includes an automatic condensate drain valve, keeping the tank clean and free of moisture. The first maintenance interval is after 10,000 hours, highlighting its reliability and low operating costs.
Technical highlights
-
Voltage: 230 V, 50 Hz - Absorption: 15 A
-
Motor: 2.2 kW (3 HP), 2 cylinders
-
Air intake: 330 L/min
-
Air delivery: 210 L/min at 5 bar, 185 L/min at 8 bar
-
Max pressure: 10 bar
-
Tank: 40 L, epoxy coated
-
Duty cycle: S1 100% continuous duty
-
Noise level: 47 dB
-
Dimensions: 800 × 660 × 920 mm
-
Weight: 162 kg (177 kg packaged)
The Gentilin Qube 300 is the ideal choice if you need a quiet, oil-free compressor with reliable airflow and a durable tank for professional daily use.
Catalog Download
Certifications Download
| Condensate Treatment | - |
|---|---|
| Particulate Treatment | - |
| Air purity class (ISO 8573-1) | X-X-0 |
| Voltage (V) | 230,00 |
| Frequency (Hz) | 50,00 |
| Nominal rating (kW) | 2,20 |
| Nominal rating (HP) | 3,00 |
| Rotation speed (rpm) | 1.400,00 |
| Absorption (A) | 15,00 |
| Number of cylinders | 2 |
| Air intake (L/min) | 330,00 |
| Air Delivery (L/min @5 bar) | 210,00 |
| Air Delivery (L/min @8 bar) | 185,00 |
| Maximum pressure (bar) | 10,00 |
| Noise level (3,00m @ 5,00 bar) (dB(A)) | 47,00 |
| Duty cycle | S1 100% |
| Tank Coating | Epoxy (interior/exterior) |
| Tank capacity (lt) | 40,00 |
| First Maintenance (hours) | 10000 |
| Hour Meter | Included |
| Tank Automatic Drain Valve | Included |
| Length (mm) | Width (mm) | Height (mm) | Weight (Kg) |
|---|---|---|---|
| 800,00 | 660,00 | 920,00 | 162,00 |
| Length (mm) | Width (mm) | Height (mm) | Weight (Kg) |
|---|---|---|---|
| 900,00 | 900,00 | 1080,00 | 177,00 |
| Dimensions (cm) - LxWxH | Weight (Kg) | Pieces |
|---|---|---|
| 900x900x1080 | 177,00 | 1 |

**All our products are brand new, shipped in the original packaging, and include manufacturer warranty**
