KERN SAUTER LB 500-2 digital calliper gauge

The LB 500 is a precise measuring device for length measurement up to 500 mm. It is designed for use directly on machines, conveyor systems, and test stands where clear and fast measurement is needed. It provides stable readings even when the slider moves quickly.

The device is built for easy mounting, making it suitable for machine tools and testing setups. It can be installed horizontally or vertically, depending on your application. The solid construction with aluminium and plastic housing ensures durability for daily use.

Operation is simple and direct. You can set zero, add or subtract preset values, and switch between mm and inch easily. The clear LCD display shows the measurement clearly during use.

The integrated interface allows connection to external systems for data transfer. This makes it useful in setups where measurement data needs to be recorded or processed.

Technical data:

Measuring range: 500 mm.
Division: 0.01 mm.
Tolerance: 3%.
Display: LCD.
Measurement alignment: horizontal and vertical.
Interface: RS-232.
Power supply: battery (CR2032).

Extra:

EX version available on request.
